Services
Since the 1980s, Pax Products has been providing metal fabrication services. We understand the industry’s need for high-quality workmanship and quick turnaround.
Pax Products’ core competencies include:
- Powder Coating
- Bead Blasting
- Laser Cutting
- CNC Folding
- CNC Bending
- Machining
- Welding
- Assembly
Key Equipment
| Powder Coating Services | |
|---|---|
| Booth Size | 20′ x 10′ x 9′ tall |
| Oven Size | 16′ x 10′ x 10′ tall |
| Coating Services | Zirconium pre-treatment, (pre-wash) |
| Masking and Unmasking | |
| Part Fabrication and Welding | |
| Parts Tumbling | |
| Laser | |
|---|---|
| Maximum Thickness | 1” for mild steel*, 3/8” for stainless steel |
| Minimum Thickness | 0.005” for mild steel |
| Positioning Tolerance | ±0.002” |
| Maximum Table size | 5’ x 10’ |
| CNC Folding Machine | |
|---|---|
| Maximum Thickness (at full width): | 6 mm for mild steel |
| Maximum Width | 128” |
| Machining | |
|---|---|
| CNC Machining Centers | 40” Travel in X direction |
| 20” Travel in Y direction | |
| 20” Travel in Z direction | |
| CNC Lathes | Maximum Turning Diameter = 10″ |
| Maximum Cutting Length = 20” | |
| CNC Mill-Turn | 19.5” Travel in X direction |
| +/-4.9” Travel in Y direction | |
| Maximum Turning Dia. = 25.9” | |
| Maximum Cutting Length = 60” | |
| Lower 10 station turret and sub spindle | |
| 5-axis machining | |
